11322913 - PIASTRA DI CHIUSURA CON PORTA LS E RIDUTTRICE INTEGRATA PVG32 - DANFOSS

PIASTRA DI CHIUSURA CON PORTA LS E RIDUTTRICE INTEGRATA PER COMANDI IDRAULICI

Model code: SVSENDS1BC2ILMM8G0000000000B2T000000000000B2L023023000000SS0KL000Q20A00

Characteristic	Value	Description
Module Type	S	Start Module
Valve Family	1	PVG16-48
Port Connection Type	B	BSP [DIN 3852-2]
T0 Facility	C	T0 Compatible
Pilot Pressure	2	23 (PVHC)
Pilot Press. Rduct. Valve Type	I	Parts in body
Continous System Pressure	L	350
Maximum System Pressure Peaks	M	400
Mounting Thread Size	M8	M8
Pilot Dump Facility	0	N/A
Connector Type	0	N/A
Additional Feature 2	00	N/A
Additional Feature 3	00	N/A
Shock Valve Facility	0	N/A
T0 Port Size	B2	G1/4
T0 Port Placement	T	Top
LX Port Size	00	N/A
LX Port Placement	0	N/A
Gauge Port Pilot Pressure Size	00	N/A
Gauge Port Pilot Pres Location	0	N/A
Pump Port Size	00	N/A
Pump Port Placement	0	N/A
Tank Port Size	00	N/A
Tank Port Placement	0	N/A
LS/LY Port Size	B2	G1/4
LS/LY Port Placement	L	Left
Width	23	23
Tie Rod Length	023	23
Pneumatic Port Size	00	N/A
Pneumatic Port Placement	0	N/A
Gauge Port Pump Pressure Size	00	N/A
Pump Port Pressure Location	0	N/A
Tie Rod Type Left	S	Through Hole
Tie Rod Type Right	S	Through Hole
Left Interface	0	N/A
Right Interface	K	PVG32-Flat-T0
Bottom Interface	L	Mounting Feet A/B
Top Interface	0	N/A
A Side Interface	00	N/A
B Side Interface	00	N/A
Primer	Q	Passivation - Transparent
Product Category	1	Standard Part
Ex Application	A	Ex h I/II
Certification	00	N/A
Additional Feature 1	00	N/A
LY (LS Return) Facility	0	N/A
Marking	0	N/A
Material	G	Gray Cast Iron
Product type	SVS_END	End Module
Voltage	0	N/A
